Automatic Blow Molding Machine - Accumulator Model

WLCPJ系列-自动挤出吹塑机-储料式机型-技术参数 WLCPJ Series-Automatic Plastic Extrusion Blow Molding Machine - Accumulator Models - Technical Parameters
型号MODEL		80ⅠA	90ⅠA	100ⅠA
制品最大容量MAX.CAPACITY OF PRODUCTIONS	L	30	50	100
螺杆直径SCREW DIAMETER	mm	80	90	100
螺杆长径比SCREWLENGTH/DIAMETER RATIO	L/D	25/1	25/1	25/1
挤出量(PE)EXTRUSION VOLUME(PE)	kg/h	90	120	180
锁模力MOULD CLAMPING FORCE	kN	160	200	300
模板尺寸(宽×高) MOULD PLATE DIMENSIONS(W×H)	mm	780×680	930×800	1250×1000
开模行程OPENING STROKE	mm	480	500	800
挤出机电机功率EXTRUSION MOTOR POWER	kW	37	45	55
加热总功率TOTAL HEATING CAPACITY	kW	26	32	38
主机外形尺寸(长×宽×高) APPEARANCE(L×W×H)	mm	3800×2700×3500	4100×2800×3800	4800×3400×4000
机器重量WEIGHT	kgs	8500	10000	12000
注：由于产品不断改进，以上数据仅供参考，如有更改恕不另行通知。
Note: Due to continuous product improvement, data above is only for reference, such as are subject to change without a separate notice.
