Three-layer Three-color Co-extrusion

WLCPJ系列 - 自动挤出吹塑机 - 三层三色共挤双工位机型 - 技术参数 WLCPJ series-Automatic Plastic Extrusion Blow Molding Machine - Tri-layer Tri-color Co-extrusion Double-station Models - Technical Parameters
型号MODEL		40+60+40I	50+75+50I	30+65+30II	35+75+35IV	45+70+45II
制品最大容量MAX.CAPACITY OF PRODUCTIONS	L	2.5	10.0	1.0×2	1.0×4	2.0×2
模头中心距离CENTRAL DISTANCE OF DIE HEAD	mm	-	-	120	100	180
螺杆直径SCREW DIAMETER	mm	406040	507550	306530	357535	457045
螺杆长径比SCREW LENGTH/DIAMETER RATIO	L/D	25/125/125/1	25/125/125/1	25/125/125/1	25/125/125/1	25/125/125/1
挤出量EXTRUSION VOLUME(PE)	kg/h	80	130	75	95	110
锁模力MOULD CLAMPING FORCE	kN	45	100	45	60	60
模板尺寸(宽×高)MOULD PLATE DIMENSIONS(W×H)	mm	350×350	450×450	350×350	450×290	400×380
开模行程OPENING STROKE	mm	250	300	250	200	280
主电机功率MOTOR POWER	kW	154.04.0	307.57.5	18.54.02.2	304.04.0	225.55.5
总功率GENERAL ASSEMBLY POWER	kW	48	92	49	70	65
主机外形尺寸(长×宽×高)APPEARANCE(L×W×H)	mm	3000×2500×2300	3600×3000×2800	3100×2500×2300	3500×2800×2500	3200×2800×2400
机器重量WEIGHT	kgs	4800	7000	4800	5500	5800
注：由于产品不断改进，以上数据仅供参考，如有更改恕不另行通知。
Note: Due to continuous product improvement, data above is only for reference, such as are subject to change without a separate notice.
